| JOHN DEERE | WZW16750 |
| SCANIA | 2643589 |
| TIRSAN | FK00021 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.67 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 28.014 |
| Clamp band | Ø 209 mm |
| Clamp band position | 45° |
| Diameter | 8.13 in |
| Distance between bolts | 4.75 in |
| Length | 262.0 mm |
| Max. operating pressure | 147.94 / 123.28 psi |
| Port angle | Position Side port -90° |
| Port thread 11 | M16 x 1.5 |
| Port thread 12 | M16 x 1.5 |
| Port: working pressure [p emax.] | 10.2/8.5 bar |
| Push-rod length | 8.35 in |
| Push-rod thread | M16 × 1.5 |
| Release pressure | 69.62 psi |
| Stroke | 2.95 / 2.95 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Thread length | 8.35 in |
| Total lenght | 14.29 in |
| Type | 30/30 |
| Type of operation | Cam |
| Version | Without boot |
| Yoke | No |
