| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 13.1 |
| Distance between holes | 4.65 x 7.17 in |
| Electrical connection | HDSCS by TYCO (AMP-MCP-Mix.1.5/2.8- 7-pole linear bayonet) |
| Max. operating pressure | 188.5 psi |
| Mounting | 3x Ø 0.35 in |
| Multi Nominal diameter (From Port 1 to x) | 0.24 / 0.20 in |
| Output force | 224.81 lbf |
| Pedal angle | 25° |
| Port thread 11 | M16 x 1.5 JED - 388-4 |
| Port thread 12 | M16 x 1.5 JED - 388-4 |
| Port thread 21 | M16 x 1.5 JED - 388-4 |
| Port thread 22 | M16 x 1.5 JED - 388-4 |
| Port thread 3 | Silencer |
| Protection class | IP 6K6K, IP 6K9K |
| Stroke | 0.83 in |
| Technical specification | OE specification |
| Temperature range | -40°F to +176°F |
| Voltage | 24 V |
| DAIMLER | A0044315006 |
