| DAF | 1395722 |
| DAF | 1455027 |
| DAF | 1315685 |
| SCANIA | 1935123 |
| SOLARIS | 1102408500 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Application | Paccar, Solaris |
| Calculated Volume (dm³) | 3.5721 |
| Distance between bolts | 2.4x2.4 in |
| Electrical connection | DIN 72585-A1-4.1-Sn/K1, EXTERNAL CONTOUR DIN 72585 NECESSARY SOCKET AMP NO. 0-96-7650-1 |
| Max. operating pressure | 145.0 psi |
| Mounting | 3x M8 |
| Multi Nominal diameter (From Port 1 to x) | 0.24 in |
| Output force | 2697.71 lbf |
| Port thread 11 | M22 x 1.5 JED - 388 |
| Port thread 12 | M22 x 1.5 JED - 388 |
| Port thread 21 | M22 x 1.5 JED - 388 |
| Port thread 22 | M22 x 1.5 JED - 388 |
| Port thread 3 | Silencer 480 001 520 2 |
| Protection class | IP 56, IP 59K |
| Silencer | 480 001 520 2 |
| Stroke | 0.55 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Thread | Voss threads |
| Type | 3 |
| Voltage | 8 to 32 V |
