WABCO威伯科制动气室4253332120 1518657 99707723401 11014309
制动气室 -- 4253332120
产品介绍
| DAF | 1518657 |
| FAUN | 99707723401 |
| NEOPLAN | 11014309 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Body | Steel |
| Calculated Volume (dm³) | 15.7164 |
| Max. operating pressure | 147.94 / 116.03 psi |
| Mounting | M45 x 1.5 |
| Output force 3 | 1910.88 lbf |
| Output force M | 1955.84 lbf |
| Port thread 11 | M16 x 1.5 |
| Port thread 12 | M16 x 1.5 |
| Port threads | M16 x 1.5 |
| Release pressure | 73.97 psi |
| Return-spring force | 33.72 lbf |
| Stroke | 2.09 / 2.09 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Thread length | 2.36 in |
| Total lenght | 15.55 in |
| Type | 20/24 |
| Type of operation | Wedge |
