感载阀 -- 4757146000
| DAF | 1506231 |
| DOLL | 7076399 |
| FAUN | 99707007541 |
| FAYMONVILLE | 51301 |
| GOLDHOFER | 167032 |
| KRONE | 9455410 |
| KRONE | 09455410 |
| LANGENDORF | 1111733 |
| MAN | 82521616032 |
| NOOTEBOOM | 308057 |
| ORTHAUS | 495166 |
| PACCAR | 1506231 |
| SCANIA | 1935110 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Break point | 5.8 psi |
| Calculated Volume (dm³) | 10.3194 |
| Comments | Static valve for trailers: Mineral oil control medium |
| Control pressure | 160 bar |
| Distance between bolts | 3.31x3.31 in |
| Inlet Pressure | 145.0 psi |
| Max. operating pressure | 145.0 psi |
| Mounting | 4x M8 |
| Port thread 1 | M22 x 1.5 |
| Port thread 2 | 2x M16 x 1.5 |
| Port thread 4 | M22 x 1.5 |
| Port thread 41 | M12 x 1.5 |
| Port thread 42 | M12 x 1.5 |
| Regulating range | 290.08 to 2030.53 psi |
| Regulating ratio | 1:8 |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Type | Hydraulic |
| Type of operation | Dynamic |
