制动信号传输器（EBS脚阀) -- 4800010000
| DAF | 1506235 |
| EVOBUS | A00443122050005 |
| EVOBUS | A0044312205 |
| MERCEDES-BENZ | 0044312205 |
| MERCEDES-BENZ | A0044312205 |
| PACCAR | 1506235 |
| SCANIA | 1935120 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Application | Mercedes-Benz |
| Calculated Volume (dm³) | 2.43 |
| Distance between bolts | 2.4x2.4 in |
| Electrical connection | 2x Bayonet DIN 72585 A1-4.1-Sn/K1 |
| Max. operating pressure | 145.0 psi |
| Mounting | 4x M8 |
| Multi Nominal diameter (From Port 1 to x) | 0.24 in |
| Output force | 4945.80 lbf |
| Port thread 11 | M22x1.5 JED - 388 |
| Port thread 12 | M22 x 1.5 JED - 388 |
| Port thread 21 | M22 x 1.5 JED - 388 |
| Port thread 22 | M22 x 1.5 JED - 388 |
| Port thread 3 | Union Ø 16.0 |
| Port thread 4 | M16x1.5 JED - 388 |
| Protection class | IP 56, IP 59K |
| Stroke | 0.55 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Voltage | 8 to 32 V |
