| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 26.08 |
| Closing pressure static 21 | 65.3 psi |
| Closing pressure static 22 | 65.3 psi |
| Closing pressure static 23 | 43.51 psi |
| Closing pressure static 24 | 65.3 psi |
| Electrical connection | HDSCS, 8-POS 1.5mm TAB, code A |
| Max. operating pressure | 181.3 psi |
| Opening pressure 21 | 108.78 psi |
| Opening pressure 22 | 108.78 psi |
| Opening pressure 23 | 130.53 psi |
| Opening pressure 24 | 123.28 psi |
| Opening pressure 25 | 123.28 psi |
| Port thread 12 | M12 x 1.5 |
| Port thread 24 | M12 x 1.5 |
| Port thread 4 | M12 x 1.5 |
| Technical specification | OE specification |
| Temperature range | -40°F to +176°F |
| Voltage | 24 V |
