离合器助力缸 -- 9700514820
| DONGFENG (DFM)/东风 | 1608010-WABCO |
| FAW/解放 | 160230554B |
| FAW/解放 | 160230554BB |
| FAW/解放 | 1602305-54B/B |
| SAIC-IVECO HONGYAN/依维柯-红岩 | 1602-500530 |
| SAIC-IVECO HONGYAN/依维柯-红岩 | 580 149 070 7 |
| SHAANXI/陕汽 | DZ91189230178 |
| SINOTRUK (CNHTC)/重汽 | WG9725230056/2 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 8.072 |
| Distance between holes | 5.12 in |
| Length | 347 mm |
| Max. operating pressure | 145.0 psi |
| Medium | Brake fluid SAE J 1703 |
| Mounting | 4x Ø 9.0 mm |
| Port thread 1-4 | M14 x 1.5 |
| Port thread 11 | M16 x 1.5 JED - 388 |
| Port thread 12 | M10 x 1.0 JED - 388-1 |
| Port thread 22 | M10 x 1.0 JED - 388-1 |
| Port thread 31 | Flap Exhaust |
| Port thread 32 | Ø 8.0 mm |
| Push-rod thread | Ball Ø 12.0 mm |
| Stroke | 2.93 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
