WABCO威伯科气缸4231079000 605107100 84012958 834484 705707 834484 8283572000 8283850000 89199797614 943 6674 6763 9628S4231079000 ASX0014021 M02027203 A3309600VAS 201241 4231079000 AZ52824 WZ2480155
气缸 -- 4231079000
产品介绍
| BENALU | 605107100 |
| CASE IH | 84012958 |
| DAF | 0834484 |
| DAF | 705707 |
| DAF | 834484 |
| EVOBUS | 8283572000 |
| EVOBUS | 8283850000 |
| EVOBUS | 89199797614 |
| FAYMONVILLE | 0943 |
| FELDBINDER | 006674 |
| FELDBINDER | 006763 |
| FREIGHTLINER | 9628S4231079000 |
| FRUEHAUF | ASX0014021 |
| FRUEHAUF | M02027203 |
| FRUEHAUF | A3309600VAS |
| GOLDHOFER | 201241 |
| HENDRICKSON | 4231079000 |
| JOHN DEERE | AZ52824 |
| JOHN DEERE | WZ2480155 |
| JOST | JAS6010440024 |
| JOST | 1155399 |
| JOST | JAS0210405224 |
| KEMPF | 2001009 |
| KENWORTH | S423-107-900-0 |
| KRONE | 945152 |
| KRONE | 50945152 |
| KÄSSBOHRER | 82830500000 |
| KÖGEL | 175204 |
| KÖGEL | 79545 |
| LANGENDORF | 1109377 |
| LECITRAILER | 4110441 |
| LEYLAND DAF | 834484 |
| LEYLAND DAF | BBU5933 |
| LIEBHERR | 502966208 |
| LIEBHERR | 502920501 |
| LOHR | 4231079000 |
| MAFI | 5680047 |
| MAFI | 0005680047 |
| MERCEDES-BENZ | 0004208024 |
| MERITOR | S4231079000 |
| NEOPLAN | 07010030 |
| NOOTEBOOM | 305052 |
| NOOTEBOOM | 0305052 |
| PACCAR | 0834484 |
| PETERBILT | S423-107-900-0 |
| RENAULT | 5000815361 |
| RENAULT | 5021170052 |
| SAF | 4454103900 |
| SCANIA | 1738481 |
| SCANIA | 1010155 |
| SCHMITZ CARGOBULL | 051017 |
| SCHMITZ CARGOBULL | 82830500000 |
| SCHMITZ CARGOBULL | 51017 |
| SCHMITZ CARGOBULL | 1232785 |
| SCHWARZMÜLLER | 3553 |
| TEREX | 96924700 |
| TIRSAN | 21151105030 |
| TOHO | T42-106 |
| VOLVO | WA4231079000 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.36 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 12.17 |
| Clamp band | 209 mm |
| Clamp band position | -45° |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 123.28 psi |
| Operating pressure | 123.3 psi |
| Output force | 2922.52 lbf |
| Output force M | 2922.52 lbf |
| Port (side) | M16 x 1.5 |
| Port (top) | M16 x 1.5 |
| Port angle | 180° |
| Port threads | M16 x 1.5 |
| Push-rod length | 7.32 in |
| Push-rod thread | M16 x 1.5 |
| Return-spring force | 22.48 lbf |
| Stroke | 2.95 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Thread length | 7.32 in |
| Total lenght | 5.04 in |
| Type | 30 |
| Type of operation | Cam |
| Version | Without boot |
| Yoke | Without |
| GTIN | 04057875164579 |
| Size (mm x mm x mm) | 297 x 197 x 208 |
| UPC | 193133457107 |
| Weight (kg) | 4.45 |
