离合器促动气缸 -- 9701500010
| EVOBUS | A0002500562 |
| MERCEDES-BENZ | 0002500562 |
| MERCEDES-BENZ | A0002500562Z001 |
| MERCEDES-BENZ | A0002500562 |
| MERCEDES-BENZ | 0002500562Z001 |
| MERCEDES-BENZ | 0002500062 |
| MERCEDES-BENZ | 0002500062Z003 |
| MERCEDES-BENZ | A0002500062 |
| MERCEDES-BENZ | A0002500062Z002 |
| MERCEDES-BENZ | A0002500062Z003 |
| MERCEDES-BENZ | A0002500562Z002 |
| MERCEDES-BENZ | 0002500562Z002 |
| PACCAR | 1527642 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 7.9168 |
| Distance between holes | 1.73x5.91 in |
| Electrical connection | Bayonet DIN 72585 A1-7.1 & Bayonet DIN 72585 A1-2.1 |
| Max. operating pressure | 123.28 psi |
| Mounting | 2x Ø 11 mm |
| Output force | 1573.66 lbf |
| Port thread 1 | M16 x 1.5 |
| Protection class | IP 67 |
| Rated current connector | 1.5 A |
| Rated current sensor (A) | 0.09 A |
| Rated current solenoid valve (A) | 1.60 A |
| Stroke | 2.74 in |
| System | EPS III |
| Technical specification | OE specification |
| Temperature range | -30°C to +90°C |
| Voltage | 12/24 V |
