WABCO威伯科制动室(凸轮制动器)4231074100 A0074209724 64204724 74209724 A0074209724 A0064204724
制动室(凸轮制动器) -- 4231074100
产品介绍
| EVOBUS | A0074209724 |
| MERCEDES-BENZ | 0064204724 |
| MERCEDES-BENZ | 0074209724 |
| MERCEDES-BENZ | A0074209724 |
| MERCEDES-BENZ | A0064204724 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.48 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 9.6344 |
| Clamp band | 209 mm |
| Clamp band position | 0° |
| Clevis pins | 14 H11 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 psi |
| Operating pressure | 147.9 psi |
| Output force | 2697.71 lbf |
| Output force M | 2697.71 lbf |
| Port (side) | M12 x 1.5 JED-152 |
| Port (top) | M22 x 1.5 JED-388 |
| Port angle | 0° |
| Port threads | M12 x 1.5 |
| Push-rod length | 2.13 in |
| Return-spring force | 56.20 lbf |
| Stroke | 2.52 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 5.22 in |
| Type | 30 |
| Type of operation | Cam |
| Version | With Boot |
| Yoke | Welded |
