WABCO威伯科制动气室9254922130 0194208218 A0194208218
制动气室 -- 9254922130
产品介绍
| MERCEDES-BENZ | 0194208218 |
| MERCEDES-BENZ | A0194208218 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Bolt lengths | 1.52 in |
| Bolt threads | M16 x 1.5 |
| Calculated Volume (dm³) | 21.5624 |
| Clevis pin | 0.55 in |
| Comments | With VOSS 232 |
| Distance between bolts | 4.75 in |
| Max. operating pressure | 147.94 / 123.28 psi |
| Opposite | 925 492 203 0 |
| Output force 3 | 2585.30 lbf |
| Output force M | 3453.07 lbf |
| Port thread 11 | M22 x 1.5 JED - 388 |
| Port thread 12 | M22 x 1.5 JED - 388 |
| Port threads | M22 x 1.5 |
| Push-rod length | 1.46 in |
| Release pressure | 73.97 psi |
| Return-spring force | 56.20 lbf |
| Stroke | 2.56 / 2.56 in |
| Technical specification | OE specification |
| Temperature range | -40°C to +80°C |
| Total lenght | 11.93 in |
| Type | 30/30 IBV |
| Type of operation | Cam |
| Version | With boot |
