WABCO威伯科ECAS电磁阀 4630841000 515015180 6503129 1272953 6281011 2090295 1105018 86427 20199001562 11183064
ECAS电磁阀 -- 4630841000
产品介绍
| KRONE | 515015180 |
| KÖGEL | 6503129 |
| LANGENDORF | 1272953 |
| LECITRAILER | 6281011 |
| SCANIA | 2090295 |
| SCHMITZ CARGOBULL | 1105018 |
| SCHWARZMÜLLER | 86427 |
| TIRSAN | 20199001562 |
| VAN HOOL | 11183064 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Actuation | Electrical |
| Application | T EBS, ECAS, Immobilizer |
| Calculated Volume (dm³) | 2.703 |
| Electrical connection | DIN 72585-A1-4.2-Sn/K2 |
| Max. operating pressure | 188.5 psi |
| Port thread 1 | M22 x 1.5 |
| Port thread 21 | M22 x 1.5 |
| Port thread 22 | M22 x 1.5 |
| Port thread 23 | M22 x 1.5 |
| Port thread 24 | M22 x 1.5 |
| Port thread 25 | M22 x 1.5 |
| Port thread 31 | M22 x 1.5 |
| Port thread 32 | Silencer 432 407 060 0 |
| Protection class | IP6K6K |
| Rated current | 340 mA |
| Technical specification | OE specification |
| Temperature range | -40°C to +65°C |
| Type | LACV-IC |
| Version | Dual-circuit |
| Voltage | 24 V |
