| DAIMLER | A0044314906 |
| DAIMLER | A0044314706 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Application | Daimler |
| Calculated Volume (dm³) | 2.033 |
| Distance between bolts | 2.4x2.4 in |
| Electrical connection | HDSCS by TYCO (AMP-MCP-Mix.1.5/2.8- 7-pole linear bayonet) |
| Max. operating pressure | 181.30 psi |
| Mounting | 4x M8 |
| Multi Nominal diameter (From Port 1 to x) | 0.24 / 0.20 in |
| Output force | 4945.80 lbf |
| Port thread 11 | M16 x 1.5 JED - 388-4 |
| Port thread 12 | M16 x 1.5 JED - 388-4 |
| Port thread 21 | M16 x 1.5 JED - 388-4 |
| Port thread 22 | M16 x 1.5 JED - 388-4 |
| Port thread 3 | Silencer |
| Protection Class | IP 6K6K, IP 6K9K |
| Stroke | 0.53 in |
| Technical specification | OE specification |
| Temperature range | -40°F to +176°F |
| Thread | Voss threads |
| Voltage (V) | 24 V |
