WABCO威伯科离合器助力缸9700514410 1527600 S9700514410 81307256104 2540447 A0002540447 A0002540447Z001 A0002540447Z002 0002540447Z002 B954237513401 S9700514410 81307256104 1527600 S9700514410 1935609
离合器助力缸 -- 9700514410
产品介绍
| DAF | 1527600 |
| KENWORTH | S9700514410 |
| MAN | 81307256104 |
| MERCEDES-BENZ | 0002540447 |
| MERCEDES-BENZ | A0002540447 |
| MERCEDES-BENZ | A0002540447Z001 |
| MERCEDES-BENZ | A0002540447Z002 |
| MERCEDES-BENZ | 0002540447Z002 |
| MERCEDES-BENZ | B954237513401 |
| MERITOR | S9700514410 |
| NEOPLAN | 81307256104 |
| PACCAR | 1527600 |
| PETERBILT | S9700514410 |
| SCANIA | 1935609 |
| Brand | WABCO |
| Part type | Premium original quality |
| Product category | Device |
| Calculated Volume (dm³) | 8.2191 |
| Comments | DC SM1 |
| Distance between holes | 4.33 in |
| Electrical connection | Bayonet DIN 72585 - A1 |
| Length | 290 mm |
| Max. operating pressure | 145.0 psi |
| Medium | Mineral oil |
| Mounting | 2x Ø 11.0 mm |
| Port thread 1-4 | M14 x 1.5 ( B ) |
| Port thread 11 | M16 x 1.5 |
| Port thread 31 | Flap Exhaust |
| Port thread 32 | Ø 8.0 mm |
| Push-rod thread | Hole Ø12.1 mm |
| Stroke | 3.35 in |
| Technical specification | OE specification |
| Temperature range | -20°C to +80°C |
| Voltage | 12 V |
